Monib Stainless, one of the leading manufacturers and suppliers from Safat, Kuwait is known to have premium quality stainless steel products. Monib Stainless is committed to precision and has been precise in its offerings by providing high-quality stainless steel solutions in a variety of sections, including Stainless Steel 304L Flanges. Appreciated for their resilience against corrosion, the strength, and versatility, these flanges are applied in sectors such as chemical processing, oil and gas, and food processing. Monib Stainless strives to offer the client a tough, reliable, and cost-effective solution catering to their unique needs around the world.
Stainless Steel 304L flanges are made of a low-carbon version of 304 steel. It exhibits excellent resistance to corrosion, particularly in chemical and marine environments. Composed of 18-20% chromium and 8-12% nickel, the small amounts of manganese, silicon, and carbon (0.03% max) make it a material with good formability and weldability but with high strength. 304L has the following mechanical properties: tensile strength of 485 MPa, yield strength of 170 MPa, and elongation of 40% in 50 mm. It is non-magnetic in the annealed condition and excellent durability under both high and low temperatures.
| Standard | ASTM A182 / ASME SA182 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges |
| Size | 1/2″ (15 NB) to 48″ (1200NB) |
| Class/Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We provides Stainless Steel 304L Flanges- Monib Stainless,which has undergone intense testing to produce top quality and performance. The flange is thoroughly tested for meeting international standards and specifications. Products supplied by us are certified by recognized authorities for traceability and reliability in each batch. With modern technology and strict quality control, we ensure durability, corrosion resistance, and good mechanical properties. Monib Stainless stands by the delivery of flanges with the highest level of industry standards in functionality and safety.
SS 304L socket weld flanges are designed for high-strength, secure connections in piping systems. Made from stainless steel 304L, they provide excellent resistance to corrosion and ease of installation.
SS 304L ring type joint flanges provide a robust seal for high-pressure applications. Made from stainless steel 304, they ensure a tight, leak-proof connection with their precision-engineered ring design.
SS 304L forged flanges are crafted from stainless steel 304L through a forging process, offering exceptional strength and durability. They are ideal for high-pressure applications and resist corrosion effectively.
Stainless Steel 304L flanges are widely available in the different industries because it has excellent resistance to corrosion properties, formability, and high-strength. Many applications include a piping system within chemical processing industries, food processing and beverage factories, pharmaceutical firms, and drinking water treatment centers. They offer excellent performance with moisture and a mild corrosive environment. These flanges are also applied in oil and gas, power generation, and construction industries to help join pipes, valves, and other components. Low carbon content makes the alloys resistant to sensitization during welding, hence having better durability and performance at higher temperatures.
